Single Phase, 240v Miniature Circuit Breaker (MCB)

Single Phase, 240v Miniature Circuit Breaker (MCB)

  • It is recommended that the power supply to your electric motor is fed directly from a miniature circuit breaker (MCB)
  • This helps protect the motor from overload – if excessive load is applied to the electric motor the MCB trips, cutting the power supply to the motor avoiding overload and failure
  • The use of MCB’s also enhances user safety
  • Three pole MCB’s also available for 3 phase motors – see codes 49-036 / 49-037
Use with Motor Motor HP Poles/Volts Amps MCB Order Code
45/46-001 3 1 / 240 16 49-034
45/46-000 3.5 1 / 240 16
45/46-008 4 1 / 240 20 49-035
45/46-002 4 3 / 415 10 49-036
45/46-003 5.5 3 / 415 10
45/46-004 7.5 3 / 415 16 49-037



Order Code: 49-034 / 49-034



Weight 0.187 kg
Model

49-034 (16 Amp), 49-035 (20 Amp)
